PN-V701

Discover the power of expression of Sharp’s 70-inch monitor for compelling video walls

Just imagine the power of a video wall built out of the PN-V701. Huge, high-impact video walls can be created using fewer monitors with less bezel interruptions across the entire on-screen image. And with upgraded colour calibration technology – SHARP Advanced UCCT – the PN-V701 gives high quality video wall solutions that are sure to attract a crowd.

  • 70″ Full HD Video wall Monitor
  • Uniform Colour Calibration Technology (UCCT)
  • 4.4 mm  bezel-to-bezel distance
  • 24/7 operation
  • Installation: Portrait or Landscape
Where to buy

Video Walls that Draw a Crowd

Video Walls that Draw a Crowd

The PN-V701 was developed specifically for use in multi-monitor installations in either portrait or landscape orientation. Thanks to its combined bezel width of just 4.4 mm*, large images on a video wall appear natural and almost seamless. The grand scale of the 70-inch monitor allows you to build video walls with fewer monitors and fewer bezels, which serves to minimise the non-displayed area. Whether in an airport, railway station, shopping mall, or other public spaces, the PN-V701 expands the creative possibilities of visual communication. * 1.5 mm (right/bottom), 2.9 mm (left/top)
Excellent Image Quality

Excellent Image Quality

The PN-V701 incorporates Sharp’s UV2A* technology to ensure highly efficient use of light from the backlight and prevent light leakage, resulting in truly bright whites and extremely deep blacks. The LCD panel also boasts 1,920 (H) x 1,080 (V)-pixel full HD resolution, making everything from fine text to intricate graphics stunningly crisp and clear. A brightness of 700 cd/m2 supports the PN-V701 in its digital signage duties. Four PN-V701 monitors set up in a 2 x 2 configuration, for example, can beautifully render every single pixel of 4K Ultra HD (3,840 x 2,160-pixel) content in a form equivalent to a huge 140-inch monitor. What’s more, the PN-V701 employs SHARP Advanced UCCT (Uniform Colour Calibration Technology) to achieve brilliant uniformity of colour and brightness across the entire video wall. * UV2A stands for Ultraviolet-induced Multi-domain Vertical Alignment, a photo-alignment technology that ensures uniform alignment of liquid crystal molecules.
Sharp Advanced UCCT (Uniform Colour Calibration Technology)

Sharp Advanced UCCT (Uniform Colour Calibration Technology)

To achieve high-quality video walls with superb uniformity of colour and brightness, Sharp developed SHARP Advanced UCCT. This unique out-of-the-box technology performs two functions: it corrects the colour and brightness within a monitor, and it reduces colour inconsistency among monitors by sophisticated colour management of each monitor. Thanks to this combination, the PN-V701 can create video walls of extremely high quality and dynamism.
Inverse Scan Function

Inverse Scan Function

When high-speed video is played on a video wall composed of multiple monitors, slight image misalignments between vertically placed monitors can occur. As a countermeasure, the Inverse Scan function comes standard with the PN-V701. This corrects image misalignments by alternating the scanning direction between vertically adjacent monitors, creating smooth and natural images on a large video wall.
Expand All
General
24 / 7 Operation
Yes
High Brightness (500+ cd/m2)
Yes
Wall Mount
Yes
Brightness
High Brightness
Display Types
Video Wall Displays
Resolution
Full HD (1920x1080)
Size
70"+
Landscape
-
Portrait
-
Lie Flat
-
System on chip
-
Stands
-
I/O Boards
-
Other
-
Accessories
Main accessories
-
Computer Input
Plug & Play
-
Power Management
-
Synchronisation
-
Video
-
Enviornmental
Operating Humidity
-
Operating Temperature
-
Input Terminal
Display Port
1
DVI-D
1
HDMI
2
Audio (3.5mm stereo mini jack)
-
Component BNC
-
Component Video
-
DVI-I
-
PC Analogue mini D-sub 15 pin
-
RCA pin (L/R)
-
RS-232C
-
USB
-
Video BNC
-
With Options
-
LCD Panel
Active Screen Area
1,538.9 x 865.6 mm
Backlight
LED, full array
Contrast Ratio
4,000 : 1
Max. Brightness (average)
700cdm
Max.Resolution
1,920 x 1,080 pixels
Pixel Pitch (H x V)
0.802 x 0.802 mm
Response Time
6 ms (grey to grey, avg.)
Viewing Angle (H/V)
178°/ 178°(CR ≧ 10)
Max. Display Colours
-
Screen
-
Output Terminal
3.5mm mini stereo jack
1
DisplayPort
1
Micro-USB
-
RCA pin(L/R)
-
Speakers
Built-in
-
External
-
Touch Pen
Button
-
Communication
-
Touchscreen
Driver
-
Multi Touch
-
PC Connection Port
-
Power Supply
-
Protection Glass Thickness
-
Touch Technology
-
Others
Dimensions (W x D x H) (approx, display only)
1,543.7 x 122 x 870.4 mm
Weight
37Kg
Mounting
-
Power Consumption
-
